Fan Coil Units

Untes, the HVAC expert, offers sustainable energy saving while bringing the most recent air conditioning technologies into the modern life. Green Line labeled fan coil units provides the comfort of home in all kinds of living environments by producing solutions and promoting sustainable systems in terms of energy productivity without sacrificing from comfort.

All capacity and electrical tests are carried out at Fan Coil Test and Research Laboratories according EN1397, ANSI-ASHRAE79, ANSI-AHRI440 and ANSI-AMCA210 standards.

Download Catalog

Home Comfort Everywhere !

• Ideal room temperature and indoor air quality for all seasons
• Wide and versatile production options
• Advanced electronic control options
• Low energy consumption and high comfort
• Outstanding safety and high quality

Types:

• GTT-Ceiling Concealed Type, rear inlet and front supply.
• GTA-Ceiling Concealed Type, bottom inlet and front supply.
• KTP-Cabinet ceiling type, bottom inlet and front supply.
• KTT-Cabinet ceiling type, rear inlet and front supply.
• KDT-Cabinet floor type, bottom inlet and top supply (Feets are optional).
• KYT-Cabinet floor type, front inlet and top supply.
• GDT-Floor type without cabinet, bottom inlet and top supply.

Structural Features:

• Produced from high zinc ratio corrosion resistant galvanized sheet and painted cabinet sheet (for cabinet types) with different color options.
• High energy efficient and silent radial fans (230V-1ph-50Hz).
• Easy access for service and cleaning due to mesh filters.
• Specially designed waterproof terminal box are used for electrical connections.
• Coils are produced from high efficient, seamless copper pipe and aluminum fins. Each coil is installed in factory after test at 20 bar pressure.
• Special drip pan is used underneath the coil that prevents air leak and allows the transfer of condensed water into the drain pan.
• Drain pan is enameled with high protection specification and self-insulated.
• Additional drip pan, made up of ABS material, are used in order to prevent dripping at the coil and valve connection.(for ceiling types).

Four Way Cassette Fan Coil Units

• Low Energy Consumption and High Comfort
• Wide and Versatile Production Options
• Cooling Capacity up to 12 kW
• Advanced Electronic Control Options
• Easy Maintenance Thanks to Front-Access Feature

UDFC Series

• Cooling capacity : 1.87 - 12.04 kW
• Heating capacity : 1.45 - 14.37 kW

Download Catalog

Structural Features:

• The units are aesthetically-designed and easy to service and operate.
• Fresh air inlet is available to make fresh air connection when required.
• Washable and reusable filters are user- and environment-friendly.
• High-quality, plastic and single suction fans make sure that the operation noise is low even when air flows are at higher velocities.
• With their slim and compact designs, the units can be easily installed in spaces such as attics.
• They can be precisely adjusted with 5-speed PSC electric motors.
• Drainage pump drains up to 650 mm in head.
• Remote controller is available as standard. Wired controller options are also available on request.
• The units can be supplied with electric heaters on request.

Types:

• 4-Way cassette

Versions:

• 2B: 2-Pipe
• 4B: 4-Pipe

Options / Accessories:

• 2-way valves and actuators (Supplied loose)
• 3-way valves and actuators (Supplied loose)
• Standard remote control
• Central or indivisual wired control options
